Components
COMPONENTS
ILLUSTRATION
Installation
INSTALLATION
PROCEDURE
1. INSTALL LOWER NO. 1 INSTRUMENT PANEL AIRBAG ASSEMBLY
(a) Connect the connector.
NOTICE:
When handling the airbag connector, take care not to damage the airbag
wire harness.
...
TC and CG Terminal Circuit
DESCRIPTION
DTC output mode is set by connecting terminals TC and CG of the DLC3.
WIRING DIAGRAM
HINT:
When each warning light continues blinking, a ground short in the wiring of terminal
TC of the DLC3 or an internal ground short in each ECU is suspec ...
